Place of Origin:
Shanghai, China
Brand Name:
YASEN
16kg Dry Cleaning Machine For Industrial Laundry Needs Solvent C₂Cl₄ Tetrachloroethylene
The working principle of a tetrachloroethylene (also known as perchloroethylene or PCE) dry cleaning machine primarily relies on the use of tetrachloroethylene as the cleaning solvent:
| Category | LS 816 | LS 820 | LS 825 |
|---|---|---|---|
| Washing Capacity (kg) | 16 | 20 | 25 |
| Capacity of volume (L) | 280 | 340 | 425 |
| Capacity of diameter (mm) | Φ900 | Φ900 | Φ900 |
| Power Supply (V/P/Hz) | 380/3/50 | 380/3/50 | 380/3/50 |
| Drive Motor Power (kw) | 2.2 | 3 | 4 |
| Hydraulic Pump Power (kw) | 0.75 | 0.55 | 0.55 |
| Power electric heating (kw) | 23.7 | 24.5 | 24.5 |
| Power steam heating (kw) | 8.7 | 9.5 | 10.5 |
| Steam pressure (MPa) | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 |
| N.W. (kg) | 1850 | 2020 | 2280 |
| Dimension (L.W.H) (mm) | 2015×1570×2250 | 2015×1662×2250 | 2015×1795×2250 |
The whole machine has been guaranteed for 1 year. Providing lifelong technical support. Guarantee of spare parts supply. Engineers available to service machinery overseas.
Main spare parts (except consumable accessories) under ONE YEAR Warranty with defects from manufacturer by free shipping.
| Category | LS-608C | LS-610C | LS-612C |
|---|---|---|---|
| Washing Capacity (kg) | 8 | 10 | 12 |
| Capacity of drum (L) | 140 | 170 | 198 |
| Washing Speed (r/min) | 38 | 38 | 38 |
| Extracting Speed (r/min) | 400 | 400 | 400 |
| Hydraulic Pump Power (kw) | 0.55 | 0.55 | 0.55 |
| Drive Motor Power (kw) | 1.5 | 2.2 | 2.2 |
| Filter Motor (kw) | 0.55 | 0.55 | 0.55 |
| Power Supply (V) | 3P/220V/380V | 3P/220V/380V | 3P/220V/380V |
| Frequency (Hz) | 50 | 50 | 50 |
| Dimension (L.W.H) (mm) | 1680×1250×1970 | 1680×1250×1970 | 1820×1330×2200 |
| N.W. (kg) | 980 | 1150 | 1280 |
