16kg Laundry Industrial Dry Cleaning Machine Needs Solvent C₂Cl₄ Tetrachloroethylene

16kg Laundry Industrial Dry Cleaning Machine Needs Solvent C₂Cl₄ Tetrachloroethylene

10kg industrial dry cleaning machine

industrial dry cleaning machine

Tetrachloroethylene industrial dry cleaning machine

Place of Origin:

Shanghai, China

Brand Name:

YASEN

Contact Us
Request A Quote
Product Details
Product Name:
Tetrachloroethylene Dry Cleaning Machine
Warranty:
1 Year
Solvent:
C2Cl4
Size:
1680*1250*1970mm
Power:
2.2kw
Weight:
1150kg
Rated Capacity(kg):
8,10,12
Diameter:
800mm
Volume:
170
Depth:
340
Centrifugal Filter Volume:
45
Brand:
YASEN
Highlight:

10kg industrial dry cleaning machine

,

industrial dry cleaning machine

,

Tetrachloroethylene industrial dry cleaning machine

Payment & Shipping Terms
Minimum Order Quantity
1pc
Price
$9,500.00/sets >=1 sets
Packaging Details
Wooden packing
Supply Ability
30 Set/Sets per Month industrial laundry dry cleaning machine
Product Description
16kg Laundry Industrial Dry Cleaning Machine Needs Solvent C₂Cl₄ Tetrachloroethylene
Product Overview

16kg Dry Cleaning Machine For Industrial Laundry Needs Solvent C₂Cl₄ Tetrachloroethylene

Working Principle

The working principle of a tetrachloroethylene (also known as perchloroethylene or PCE) dry cleaning machine primarily relies on the use of tetrachloroethylene as the cleaning solvent:

  • Action of the Solvent: Tetrachloroethylene exhibits a high degreasing ability, allowing it to effectively remove stubborn oil and dirt stains from garments.
  • Heating and Rotation: During the cleaning process, the solvent is heated to a temperature of around 40-50°C, while the garments are rotated at a high speed inside the cleaning chamber. This combination of heat and agitation produces rich foam and agitates the garments, effectively loosening and removing dirt and stains.
  • Filtration System: The solvent circulation system incorporates a filtration system that removes impurities and dirt washed off from the garments, preventing them from redepositing on the garments.
Key Advantages
  • High Cleaning Efficiency: Tetrachloroethylene's excellent degreasing properties ensure thorough removal of various stubborn stains from garments, suitable for cleaning fabrics such as cotton-polyester blends, wool, fur, velvet, synthetic fibers, and down jackets.
  • Fabric Protection: After cleaning with tetrachloroethylene, garments retain their original color, do not shrink, and do not develop wrinkles. It also has antibacterial and insecticide properties, effectively protecting the quality of the garments.
  • Environmental Friendliness and Energy Efficiency: The use of an efficient recovery system significantly reduces residual tetrachloroethylene, protecting the work environment and the health of employees. This also contributes to environmental compliance.
  • Ease of Operation: Tetrachloroethylene dry cleaning machines are equipped with computer-controlled systems, allowing for both manual and automatic control of the cleaning process, making operation simple and straightforward.
  • Durable Construction: High-quality stainless steel construction and advanced anti-corrosion treatment ensure long-lasting durability of parts that come into contact with the solvent, such as the inner drum and distillation tank.
  • Flexibility: Depending on the specific cleaning requirements of different fabrics and leather garments, the tetrachloroethylene dry cleaning machine can automatically adjust the speed of washing and drying to meet various cleaning needs.
Technical Specifications - LS Series
CategoryLS 816LS 820LS 825
Washing Capacity (kg)162025
Capacity of volume (L)280340425
Capacity of diameter (mm)Φ900Φ900Φ900
Power Supply (V/P/Hz)380/3/50380/3/50380/3/50
Drive Motor Power (kw)2.234
Hydraulic Pump Power (kw)0.750.550.55
Power electric heating (kw)23.724.524.5
Power steam heating (kw)8.79.510.5
Steam pressure (MPa)0.4-0.60.4-0.60.4-0.6
N.W. (kg)185020202280
Dimension (L.W.H) (mm)2015×1570×22502015×1662×22502015×1795×2250
16kg Laundry Industrial Dry Cleaning Machine Needs Solvent C₂Cl₄ Tetrachloroethylene 0
Key Features
  • With washing, extracting, and drying function in one machine
  • Fully automatic and fully enclosed, easy to operate, repair and testing more convenient
  • Stainless steel drum, good appearance
  • With recycle working system, recycling rate can reach to 99.8%, save solvent (perchloroethylene), no pollution to the air, no harm to the users
  • Heating type: electricity or steam
After Sales Service

The whole machine has been guaranteed for 1 year. Providing lifelong technical support. Guarantee of spare parts supply. Engineers available to service machinery overseas.

Installation and Testing
  • Free technical train at factory
  • Free technical guide through network
  • On-site service under contract
Warranty

Main spare parts (except consumable accessories) under ONE YEAR Warranty with defects from manufacturer by free shipping.

Additional Product Parameters - LS-C Series
CategoryLS-608CLS-610CLS-612C
Washing Capacity (kg)81012
Capacity of drum (L)140170198
Washing Speed (r/min)383838
Extracting Speed (r/min)400400400
Hydraulic Pump Power (kw)0.550.550.55
Drive Motor Power (kw)1.52.22.2
Filter Motor (kw)0.550.550.55
Power Supply (V)3P/220V/380V3P/220V/380V3P/220V/380V
Frequency (Hz)505050
Dimension (L.W.H) (mm)1680×1250×19701680×1250×19701820×1330×2200
N.W. (kg)98011501280
16kg Laundry Industrial Dry Cleaning Machine Needs Solvent C₂Cl₄ Tetrachloroethylene 116kg Laundry Industrial Dry Cleaning Machine Needs Solvent C₂Cl₄ Tetrachloroethylene 2
Customer Evaluation
16kg Laundry Industrial Dry Cleaning Machine Needs Solvent C₂Cl₄ Tetrachloroethylene 3
Packaging and Shipping
16kg Laundry Industrial Dry Cleaning Machine Needs Solvent C₂Cl₄ Tetrachloroethylene 4
Frequently Asked Questions
Q1: Are you manufacturer? I don't want to cooperate with trading company.
Yes, we are the manufacturer. We are a professional washing machine factory with more than 28 years manufacturing experience. You are welcome to visit our factory at your any time and checking our machines on site.
Q2: If I purchase washer extractor and dryer from your company, will you provide free spare parts?
Yes, the manufacturer shall provide one-year warranty for main parts of the machine (excluding vulnerable parts). In case of quality problems in normal use, spare parts will be provided free of charge from the original manufacturer.
Q3: How about the Certification?
Our industrial laundry equipment are certificated by CE; Our factory adopts the management system of ISO9001 and ISO14001.
Q4: How about the Voltage?
The voltage will be customized according to your local requirement; Different voltage and frequency to meet different countries' power standard.
Q5: How about the quality warranty?
We have strict control of quality from material to shipment. We have a good quality control system. Every step will be checked during manufacturing.
Q6: What is the production leading time?
For regular models, it takes 10-20 days for delivery. For customized items according to order conditions.
Q7: When you have some doubts about washer extractor using?
Please chat to our on-line technician, who are ready to assist you in 24 hours/day.
