Place of Origin:
Shanghai, China
Brand Name:
YASEN
Certification:
CE&ISO9001
Model Number:
SXT-150,200,300,500,700,1000F,FX
SXT-F Series Washer-extractor is suitable for hotels, restaurants, hospitals, garment factories, industrial-mining enterprises, and individual washing-dyeing operations. It is used for washing cotton, wool, chemical fiber, and other fabrics.
Main spare parts (except consumable accessories) under ONE YEAR warranty with defects from manufacturer by free shipping.
| Model | SXT-150F | SXT-200F | SXT-300F | SXT-500F | SXT-700F | SXT-1000F | SXT-1500F |
|---|---|---|---|---|---|---|---|
| Rated Capacity (kg) | 15 | 20 | 30 | 50 | 70 | 100 | 150 |
| Drum Dimension (mm) | Φ636×472 | Φ730×450 | Φ900×470 | Φ970×650 | Φ1200×620 | Φ1200×840 | Φ1470×880 |
| Washing Speed (r/min) | 42 | 42 | 40 | 40 | 35 | 35 | 30 |
| Extracting Speed (r/min) | 850 | 800 | 770 | 740 | 670 | 670 | 610 |
| Rated Voltage (V) | 3P/220V/380V | ||||||
| Motor Power (kw) | 1.5 | 2.2 | 3 | 4 | 7.5 | 7.5 | 15 |
| Water Inlet (lnch) | G3/4" | G1" | G1" | G1.5" | G1.5" | G1.5" | G2" |
| Steam Inlet (lnch) | G1/2" | G1/2" | G3/4" | G1" | G1" | G1" | G1.5" |
| Electric Heating Power (kw) | 9 | 18 | 27 | 36 | 54 | 72 | - |
| Steam Pressure (Mpa) | 0.3-0.5 | ||||||
| Consumes Proportion of Steam (kg/kg) | 0.5 | ||||||
| Drainage Dimension (mm) | Φ60 | Φ60 | Φ80 | Φ90 | Φ127 | Φ127 | Φ127x2 |
| Air Pressure (Mpa) | 0.4-0.6 | ||||||
| Noise dB(A) | <78 | ||||||
| Dimension W×D×H (mm) | 1150×1050×1510 | 1200×1100×1620 | 1340×1450×1750 | 1510×1600×1780 | 1750×1800×1980 | 1920×2150×1990 | 2150×2420×2350 |
| N.W. (kg) | 450 | 550 | 1300 | 1500 | 2800 | 3200 | 5500 |
