Self Service Hotel Laundry Washing Machine Equipment For Cleaning

Self Service Hotel Laundry Washing Machine Equipment For Cleaning

hotel laundry washing machine

self service washer extractor

commercial cleaning equipment with warranty

Place of Origin:

Shanghai, China

Brand Name:

YASEN

Certification:

CE,ISO9001:2008

Model Number:

SXT-150,200,300,500,700,1000F

Contact Us
Request A Quote
Product Details
Warranty:
1 Year
After-sales Service Provided:
Video Technical Support, Field Installation, Commissioning And Training, Free Spare Parts, Online Support
Capacity:
20kg,50kg,70kg,100kg,150kg
Heating Type:
Steam Or Electicity Heating
Feature:
Critical Cleaning/Residue Free
Material:
Stainless Steel
Cleaning Process:
Hot Water Cleaning
Cleaning Type:
Clean-In-Place (CIP)
Industry Used:
Hotel And Laundry
Voltage:
380V
Port:
SHANGHAI
Highlight:

hotel laundry washing machine

,

self service washer extractor

,

commercial cleaning equipment with warranty

Payment & Shipping Terms
Minimum Order Quantity
1pc
Price
$2,500.00/sets >=1 sets
Packaging Details
Wooden packaging for washer extractor
Supply Ability
100 Set/Sets per Month for washer extractor
Product Description
Self Service Hotel Laundry Washing Machine Equipment For Cleaning
Self Service Hotel Laundry Washing Machine Equipment For Cleaning 0 Self Service Hotel Laundry Washing Machine Equipment For Cleaning 1
Applications

SXT-F Series Washer-extractor is suitable for hotels, restaurants, hospitals, garment factories, industrial-mining enterprises as well as individual washing-dyeing operations. It is used for washing cotton, wool, woolen, chemical fiber and other fabrics.

Product Features
Full-Automatic Computer Control System
  • SXT-F washer-extractor has professional computer control system with excellent capacity and superior functionality
  • Contains 30 programmable procedures and 5 standard programs
  • All designs are user-friendly and intuitive
  • Users can control work liquid-level, wash temperature, wash time to efficiently satisfy washing requirements in different situations
High Strength & Long Durability
  • Creative structure from drum design using excellent stainless steel ensures prolonged machine lifespan during overload situations
  • Advanced limit principle design with outer vat made by stainless steel (50-150 kg) for corrosion resistance and high stability
  • High-strength big shaft-pedestal and high-accuracy short shaft design effectively reduces transverse vibration moment
  • Bearing of major shaft adopts high-accuracy core for extended lifespan and durability
  • Major shaft seal technology has acquired state invention patent with double water-proof design
  • Uses imported seal material of fluorine rubber with special compartment design to protect bearing and improve lifespan
Industry-Leading Vibration Control
  • Scientifically added overload weight at the front of suspended object combines gravity and vibration source center
  • Achieves perfect balance of suspended object during operation
  • High-efficiency vibration-proof springs with effective vibration-reducing rate to 98%
Excellent Design & Fine Production
  • Frequency-conversion drives with endless speed adjusting for stable, quiet operation
  • High-quality bearings for long lifespan
  • Imported seal material for major shaft with patent technology design effectively resists high temperature and super acid-alkali
  • Stainless steel panel with high corrosion proof (back panel is galvanized)
  • Safe door-lock union device with patent technology ensures operational safety
  • Five compartment automatic detergent adding system with nylon combination injection moulding structure for high corrosion proof
  • Larger diameter loading door with human-centered design for convenient loading and unloading, reducing labor strength
  • Available with steam heating or hot water heating options
After Sales Service
  • The whole machine has been guaranteed for 1 year
  • Providing lifelong technical support
  • Guarantee of spare parts supply
  • Engineers available to service machinery overseas
Product Parameters
Attributes SXT-150F SXT-200F SXT-300F SXT-500F SXT-700F SXT-1000F SXT-1500F
Rated Capacity (kg) 15 20 30 50 70 100 150
Drum Dimension (mm) Φ636×472 Φ730×450 Φ900×470 Φ970×650 Φ1200×620 Φ1200×888 Φ1470×880
Washing Speed (r/min) 42 42 40 50 35 35 30
Extracting Speed (r/min) 850 800 770 740 670 670 610
Rated Voltage (V) 220/380/415 220/380/415 220/380/415 220/380/415 220/380/415 220/380/415 220/380/415
Motor Power (kw) 1.5 2.2 3 4 7.5 7.5 15
Water Inlet (Inch) G3/4" G1" G1" G1.5" G1.5" G1.5" G2"
Steam Inlet (Inch) G1/2" G1/2" G3/4" G1" G1" G1" G1.5"
Electric Heating Power (kw) 9 18 27 36 54 72 -
Steam Pressure (Mpa) 0.3-0.5 0.3-0.5 0.3-0.5 0.3-0.5 0.3-0.5 0.3-0.5 0.3-0.5
Consumes Proportion of Steam (kg/kg) 0.5 0.5 0.5 0.5 0.5 0.5 0.5
Drainage Dimension (mm) Φ60 Φ60 Φ80 Φ90 Φ127 Φ127 Φ127x2
Air Pressure (Mpa) 0.4-0.6 0.4-0.6 0.4-0.6 0.4-0.6 0.4-0.6 0.4-0.6 0.4-0.6
Noise dB(A) <78 <78 <78 <78 <78 <78 <78
Dimension W×D×H (mm) 1200×1060×1230 1025×1000×1400 1340×1380×1700 1570×1455×1780 1750×1800×1980 1920×2150×1990 2150×2420×2350
N.W. (kg) 520 680 1500 2200 2800 3200 5500
Self Service Hotel Laundry Washing Machine Equipment For Cleaning 2 Self Service Hotel Laundry Washing Machine Equipment For Cleaning 3 Self Service Hotel Laundry Washing Machine Equipment For Cleaning 4 Self Service Hotel Laundry Washing Machine Equipment For Cleaning 5 Self Service Hotel Laundry Washing Machine Equipment For Cleaning 6 Self Service Hotel Laundry Washing Machine Equipment For Cleaning 7
