Place of Origin:
Shanghai, China
Brand Name:
YSAEN
Certification:
CE,ISO9001:2008
Model Number:
1500FX
Industrial washing machines are robust and specialized equipment designed for heavy-duty cleaning tasks. These machines are essential in various industries such as healthcare, hospitality, food processing, and manufacturing, where high volumes of laundry or equipment need to be cleaned efficiently and effectively.
Industrial washing machines are engineered to handle large loads of laundry or cleaning tasks that exceed the capabilities of domestic or commercial-grade machines. They are built with durable materials and advanced technology to ensure reliability, efficiency, and longevity.
| Model | SXT-1000FX | SXT-1500FX |
|---|---|---|
| Rated Capacity (kg) | 100 | 150 |
| Drum Dimension (mm) | Φ1200×888 | Φ1470×880 |
| Washing Speed (r/min) | 35 | 30 |
| Extracting Speed (r/min) | 670 | 610 |
| Rated Voltage (V) | 3P/220V/380V | 3P/220V/380V |
| Motor Power (kw) | 7.5 | 15 |
| Tiling Angle of Unloading | 20 | 20 |
| Water Inlet (inch) | G1.5" | G2" |
| Steam Inlet (inch) | G1" | G1.5" |
| Electric Heating Power (kw) | 72 | - |
| Steam Pressure (Mpa) | 0.3-0.5 | 0.3-0.5 |
| Consumes Proportion of Steam (kg/kg) | 0.5 | 0.5 |
| Drainage Dimension (mm) | Φ127 | Φ127×2 |
| Air Pressure (Mpa) | 0.4-0.6 | 0.4-0.6 |
| Noise dB(A) | Less than 78 | Less than 78 |
| Dimension W×D×H (mm) | 2050×2000×2260 | 2270×2450×2460 |
| Net Weight (kg) | 3620 | 5700 |
Full-Automatic Computer Control System: SXT-FX washer-extractor features professional computer control system with excellent capacity and superior functionality. Contains 30 programmable procedures and 5 standard programs with human-centric design. Users can control work liquid-level, wash temperature, and wash time to efficiently satisfy washing requirements in different situations.
High Strength & Long Durability: Creative structure from drum design using excellent stainless steel ensures prolonged machine lifespan during overload situations. Advanced limit principle design with stainless steel outer vat resists corrosion and provides high stability. High-strength big shaft-pedestal and high-accuracy short shaft design effectively reduce transverse vibration moment.
Minimal Vibration Operation: Scientifically added overload weight at the front of suspended object combines gravity and vibration source center in working state, achieving perfect balance. Vibration-proof springs provide effective vibration-reducing rate up to 98%.
Quality Production: Frequency-conversion drives enable endless speed adjustment with stable, quiet operation. High-quality bearings ensure long lifespan. Imported seal material with patent technology design effectively resists high temperature and super acid-alkali conditions.
