Place of Origin:
Shanghai, China, Shanghai China (Mainland)
Brand Name:
YASEN
Certification:
ISO,CE
![]()
Main parameters:
| Specification Model | Unit |
HG-300D
| HG-1000Z | HG-2000Z |
| Rated Capacity | kg | 15 | 50 | 100 |
| Drum | ||||
| Dimeter | mm | 800 | 1180 | 1450 |
| Dimeter depth | mm | 600 | 870 | 1050 |
| Drum Speed | rpm | 48 | 35 | 28 |
| Power Supply | V/p/Hz | 380/3/50 | 380/3/50 | 380/3/50 |
| Motor Power | kW | 0.55 | 1.1 | 2.2 |
| Fan Motor Power | kW | 0.55 | 1.1 | 1.5×2 |
| Heating Type | Electricity Heating
| Steam Heating |
Steam Heating | |
| Electric Heating Power | kW | 13 —— | -- | 83 —— |
| Steam Pipe Diameter | mm | G3/4" | -- | G2" |
| Steam Pressure | MPa | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 |
| Machine Weight | kg | 420 | 510 | 750 |
| Dimension (W×D×H) | mm | 850X1100X1600 | 1310X1550X2200 | 1620×1860×2530 |
![]()
![]()
