380V Automatic / Semi Automatic Carpet Industrial Laundry Ironing Washing Machine

380V Automatic / Semi Automatic Carpet Industrial Laundry Ironing Washing Machine

380V industrial laundry washing machine

automatic carpet ironing machine

semi automatic washer extractor

Place of Origin:

Shanghai, China

Brand Name:

YASEN

Certification:

CE,ISO9001:2008

Model Number:

SXT-150,200,300,500,700,1000F

Contact Us
Request A Quote
Product Details
Warranty:
1 Year
After-sales Service Provided:
Video Technical Support, Field Installation, Commissioning And Training, Free Spare Parts, Online Support
Capacity:
20kg,50kg,70kg,100kg,150kg
Heating Type:
Steam Or Electicity Heating
Feature:
Critical Cleaning/Residue Free
Material:
Stainless Steel
Cleaning Process:
Hot Water Cleaning
Cleaning Type:
Clean-In-Place (CIP)
Industry Used:
Hotel And Laundry
Voltage:
380V
Port:
SHANGHAI
Highlight:

380V industrial laundry washing machine

,

automatic carpet ironing machine

,

semi automatic washer extractor

Payment & Shipping Terms
Minimum Order Quantity
1pc
Price
$2,500.00/sets >=1 sets
Packaging Details
Wooden packaging for washer extractor
Supply Ability
100 Set/Sets per Month for washer extractor
Product Description
380V Automatic / Semi Automatic Carpet Industrial Laundry Ironing Washing Machine
380V Automatic / Semi Automatic Carpet Industrial Laundry Ironing Washing Machine 0 380V Automatic / Semi Automatic Carpet Industrial Laundry Ironing Washing Machine 1
Applications

SXT-F Series Washer-extractor is suitable for hotels, restaurants, hospitals, garment factories, industrial-mining enterprises, and individual washing-dyeing operations. It is used for washing cotton, wool, woolen, chemical fiber, and other fabrics.

Product Features
Full-Automatic Computer Control System
  • Professional computer control system with excellent capacity and superior functionality
  • Contains 30 programmable procedures and 5 standard programs
  • User can control work liquid-level, wash temperature, wash time to efficiently satisfy different washing requirements
  • Ergonomic design for user-friendly operation
High Strength & Long Durability
  • Creative stainless steel drum design ensures prolonged machine lifespan during overload situations
  • Advanced limit principle design with stainless steel outer vat (50-150 kg capacity) for corrosion resistance and high stability
  • High-strength big shaft-pedestal and high-accuracy short shaft design effectively reduces transverse vibration moment
  • High-precision bearing core prolongs use lifespan and durability
  • State invention patent seal technology with double water-proof design, imported fluorine rubber seal material, and special compartment design
Industry-Leading Vibration Control
  • Scientifically added overload weight at front of suspended object combines gravity and vibration source center
  • Reaches perfect balance of suspended object during operation
  • High-efficiency vibration-proof springs with effective vibration-reducing rate up to 98%
Excellent Design & Fine Production
  • Frequency-conversion drives with endless speed adjustment for stable, quiet operation
  • High-quality bearings for long lifespan
  • Imported seal material for major shaft with patent technology design effectively resists high temperature and super acid-alkali
  • Stainless steel panel with high corrosion proof (back panel is galvanized)
  • Patent technology safe door-lock union device ensures operator safety
  • Five compartment automatic detergent adding system with nylon combination injection moulding structure for high corrosion resistance
  • Larger diameter loading door with ergonomic design for convenient loading and unloading, reducing labor intensity
  • Steam heating and hot water heating options available
After Sales Service
  • Whole machine guaranteed for 1 year
  • Lifelong technical support
  • Guarantee of spare parts supply
  • Engineers available to service machinery overseas
Product Parameters
SXT Series Attributes SXT-150F SXT-200F SXT-300F SXT-500F SXT-700F SXT-1000F SXT-1500F
Rated Capacity (kg) 15 20 30 50 70 100 150
Drum Dimension (mm) Φ636×472 Φ730×450 Φ900×470 Φ970×650 Φ1200×620 Φ1200×888 Φ1470×880
Washing Speed (r/min) 42 42 40 50 35 35 30
Extracting Speed (r/min) 850 800 770 740 670 670 610
Rated Voltage (V) 220/380/415 220/380/415 220/380/415 220/380/415 220/380/415 220/380/415 220/380/415
Motor Power (kw) 1.5 2.2 3 4 7.5 7.5 15
Water Inlet (lnch) G3/4" G1" G1" G1.5" G1.5" G1.5" G2"
Steam Inlet (lnch) G1/2" G1/2" G3/4" G1" G1" G1" G1.5"
Electric Heating Power (kw) 9 18 27 36 54 72 -
Steam Pressure (Mpa) 0.3-0.5 0.3-0.5 0.3-0.5 0.3-0.5 0.3-0.5 0.3-0.5 0.3-0.5
Steam Consumption (kg/kg) 0.5 0.5 0.5 0.5 0.5 0.5 0.5
Drainage Dimension (mm) Φ60 Φ60 Φ80 Φ90 Φ127 Φ127 Φ127x2
Air Pressure (Mpa) 0.4-0.6 0.4-0.6 0.4-0.6 0.4-0.6 0.4-0.6 0.4-0.6 0.4-0.6
Noise dB(A) <78 <78 <78 <78 <78 <78 <78
Dimension W×D×H (mm) 1200×1060×1230 1025×1000×1400 1340×1380×1700 1570×1455×1780 1750×1800×1980 1920×2150×1990 2150×2420×2350
Net Weight (kg) 520 680 1500 2200 2800 3200 5500
380V Automatic / Semi Automatic Carpet Industrial Laundry Ironing Washing Machine 2 380V Automatic / Semi Automatic Carpet Industrial Laundry Ironing Washing Machine 3 380V Automatic / Semi Automatic Carpet Industrial Laundry Ironing Washing Machine 4 380V Automatic / Semi Automatic Carpet Industrial Laundry Ironing Washing Machine 5 380V Automatic / Semi Automatic Carpet Industrial Laundry Ironing Washing Machine 6 380V Automatic / Semi Automatic Carpet Industrial Laundry Ironing Washing Machine 7
