Weighing Machine Of The Washing System

Weighing Machine Of The Washing System

IWS integrated washing system weighing machine

washing system weighing scale

industrial weighing machine for washing system

Contact Us
Request A Quote
Product Details
Product Name:
Intelligent Integrated Washing System Weighing Machine
Net Weight:
320kg
Application:
IWS Integrated Washing System
Overall Dimensions (W×D×H):
3000×1245×860
Feature:
High-Accuracy Sensors
Rated Load Capacity:
>150kg
Payment & Shipping Terms
Product Description
Weighing Machine Of The Washing System
Attribute Value
Product name Intelligent Integrated Washing System Weighing Machine
Net Weight 320kg
Application IWS Integrated Washing System
Overall Dimensions (W×D×H) 3000×1245×860
Feature High-Accuracy Sensors
Rated Load Capacity >150kg
Product Features
  • Precision Weighing The weighing machine rapidly and accurately measures linen weight, optimizing distribution processes within the automated washing system.
  • Automated Conveyor Control If the linen weight exceeds the preset limit, the system automatically prevents the batch from advancing to the loading conveyor, ensuring operational safety and efficiency.
  • High-Accuracy Sensors Equipped with precision sensors to guarantee reliable and exact weight measurements.
  • User-Friendly Weight Display Simple operation: workers place linens on the machine, and weight data is instantly displayed.
  • Integrated Feeding Position Designed as a horizontal conveyor belt, it serves as a centralized feeding point, reducing physical strain during loading.
  • Multi-Person Loading & Distribution Allows loose, even spreading of linens and supports simultaneous feeding by multiple operators, improving workflow flexibility.

Technical Parameters
Parameter Unit CZ-3000
Rated Load Capacity kg ≥150
Conveyor Belt Width mm 1000
Power Supply V/Ph/Hz 380/3/50
Conveyor Motor Power kW 0.75
Net Weight kg 320
Overall Dimensions (W×D×H) mm 3000×1245×860

System Integration & Industry Applications

This intelligent weighing machine is designed for seamless integration with automated washing systems, providing accurate weight measurement and process control for industrial laundry operations.
