Place of Origin:
Shanghai, China
Brand Name:
YASEN
Certification:
CE,ISO9001:2008
Model Number:
SXT-150,250,350,500,700,1000F
SXT-F Series Washer-extractor is suitable for hotels, restaurants, hospitals, garment factories, industrial-mining enterprises, and individual washing-dyeing operations. It is used for washing cotton, wool, chemical fiber, and other fabrics.
Professional computer control system with excellent capacity and superior functionality. Contains 30 programmable procedures and 5 standard programs, all designed with user-friendly features. Users can control work liquid-level, wash temperature, and wash time to efficiently satisfy washing requirements in different situations.
Creative stainless steel drum design ensures prolonged machine lifespan during overload situations. Advanced limit principle design with outer vat made of stainless steel (50-150 kg) provides corrosion resistance and high stability. High-strength big shaft-pedestal and high-accuracy short shaft design effectively reduce transverse vibration moment. High-precision bearing core prolongs use lifespan and durability. Major shaft seal technology with state invention patent features double water-proof design, imported fluorine rubber seal material, and special compartment design to protect bearings and improve lifespan.
Scientifically added overload weight at the front of suspended object combines gravity of suspended object and center of vibration source in working state, achieving perfect balance. Vibration-proof spring efficiency provides effective vibration-reducing rate up to 98%.
Main spare parts (except consumable accessories) under ONE YEAR Warranty with defects from manufacturer by free shipping.
| Model | SXT-150F | SXT-200F | SXT-300F | SXT-500F | SXT-700F | SXT-1000F | SXT-1500F |
|---|---|---|---|---|---|---|---|
| Rated Capacity (kg) | 15 | 20 | 30 | 50 | 70 | 100 | 150 |
| Drum Dimension (mm) | Φ636×472 | Φ730×450 | Φ900×470 | Φ970×650 | Φ1200×620 | Φ1200×840 | Φ1470×880 |
| Washing Speed (r/min) | 42 | 42 | 40 | 40 | 35 | 35 | 30 |
| Extracting Speed (r/min) | 850 | 800 | 770 | 740 | 670 | 670 | 610 |
| Rated Voltage (V) | 3P/220V/380V | 3P/220V/380V | 3P/220V/380V | 3P/220V/380V | 3P/220V/380V | 3P/220V/380V | 3P/220V/380V |
| Motor Power (kw) | 1.5 | 2.2 | 3 | 4 | 7.5 | 7.5 | 15 |
| Water Inlet (lnch) | G3/4" | G1" | G1" | G1.5" | G1.5" | G1.5" | G2" |
| Steam Inlet (lnch) | G1/2" | G1/2" | G3/4" | G1" | G1" | G1" | G1.5" |
| Electric Heating Power (kw) | 9 | 18 | 27 | 36 | 54 | 72 | - |
| Steam Pressure (Mpa) | 0.3-0.5 | 0.3-0.5 | 0.3-0.5 | 0.3-0.5 | 0.3-0.5 | 0.3-0.5 | 0.3-0.5 |
| Consumes Proportion of Steam (kg/kg) | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 |
| Drainage Dimension (mm) | Φ60 | Φ60 | Φ80 | Φ90 | Φ127 | Φ127 | Φ127x2 |
| Air Pressure (Mpa) | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 |
| Noise dB(A) | <78 | <78 | <78 | <78 | <78 | <78 | <78 |
| Dimension W×D×H (mm) | 1150×1050×1510 | 1200×1100×1620 | 1340×1450×1750 | 1510×1600×1780 | 1750×1800×1980 | 1920×2150×1990 | 2150×2420×2350 |
| N.W. (kg) | 450 | 550 | 1300 | 1500 | 2800 | 3200 | 5500 |
