Home > Products > Flatwork Ironer >

5 Rolls Clean Sheet Automatic Laundry Flatwork Ironer With Steam Heating Function

5 Rolls flatwork ironer laundry equipment

Steam Heating flatwork ironer laundry equipment

Place of Origin:

Shanghai, China

Brand Name:

YASEN

Certification:

CE/OHSAS18001/ISO14001

Request A Quote

5 Rolls Clean Sheet Automatic Laundry Flatwork Ironer With Steam Heating Function

Product Details

Heating:

Steam Heating Function

Power:

5.5kw

Product Name:

High-speed Roller Duplex Flatwork Ironer

Weight:

7800kg

Used For:

Hotel Laundry Hospital

Size:

4550*3450*2020mm

Function:

Ironing Sheet

Material:

Stainless Steel

Power Supply:

380/3/50 (V/P/Hz)

Brand:

YASEN

Highlight:

5 Rolls flatwork ironer laundry equipment

Steam Heating flatwork ironer laundry equipment

Payment & Shipping Terms

Minimum Order Quantity

1pc

Price

$42,800.00 - $52,500.00/sets

Fully Automatic Flatwork Ironer Machine for Commercial Laundry

Get Best Price

800mm Roll Diameter Single Roller Iron Steam for Prison Laundry Shop Flatwork Ironing

Get Best Price

3050kg Stainless Steel Ironing Bedsheet And Clothes Folding Machine With Iron Function

Get Best Price

5 Rolls Clean Sheet Automatic Laundry Flatwork Ironer With Steam Heating Function

Get Best Price

Contact Now

Product Description

5 Rolls Clean Sheet Automatic Laundry Flatwork Ironer With Steam Heating Function

The 5 rolls clean sheet automatic laundry flatwork ironer with steam heating function is a specialized piece of equipment designed to efficiently iron large quantities of flatwork such as sheets, towels, and tablecloths. This equipment is commonly used in commercial laundries, hotels, and hospitals where high-quality laundry services are required.

The ironer is equipped with 5 heated rollers that rotate to iron the laundry. The rollers are coated with a non-stick material to prevent the laundry from sticking to them. The temperature and speed of the rollers can be adjusted to suit different types of laundry.

Application

The 5 rolls clean sheet automatic laundry flatwork ironer with steam heating function is commonly used in commercial laundries, hotels, and hospitals. It is also used in the hospitality industry for ironing tablecloths, napkins, and other linens.

Advantages

High Capacity: The ironer has a high capacity of up to 5 rolls, making it ideal for businesses that need to process large volumes of laundry regularly.
User-Friendly: The ironer is easy to operate and maintain, with user-friendly controls and simple maintenance procedures.
Energy-Efficient: The ironer is designed to be energy-efficient, with features such as automatic shut-off and adjustable temperature settings that help to reduce energy costs.
Durable: The ironer is built to withstand heavy-duty use, making it a reliable investment for businesses that rely on commercial laundry equipment.
Customizable: The ironer can be customized to suit the specific needs of different businesses. For example, the size and shape of the ironer can be adjusted to fit the available space in the laundry room.
Easy to Clean: The ironer features easy-to-clean surfaces that make it simple to maintain and keep in good condition.
Low Maintenance: The ironer requires minimal maintenance, with easy-to-clean surfaces and simple maintenance procedures.
Environmental-Friendly: The ironer is designed to be environmentally friendly, with features such as low water consumption and energy-efficient heating systems.
Cost-Effective: The ironer is a cost-effective solution for businesses that need to process large volumes of laundry regularly. It is also a reliable investment that can help to improve the quality of laundry services and increase customer satisfaction.

Product Parameters

Attributes	Y-2500I	Y-3000II	Y-3300III
Max Feeding Width(mm)	2500	3000	3300
Rolls Quantity	1	2	3
Roll Diameter(mm)	800	800	800
Ironing Speed(m/min)	0-9	0-18	0-25
Electric Heating Power(kw)	27	64	96
Steam Presure(Mpa)	0.3--0.6	0.3--0.6	0.3--0.6
Steam Consumption(kg/h)	120	250	320
Steam lnlet(lnch)	G1.5"	G1.5"	G1.5"
Drain Outlet(lnch)	G1.5"	G1.5"	G1.5"
Gas Consumption(m³/h)	6m³	12m³
Gas lnlet(lnch)	G1.5"	G1.5"
Rated-Voltage(V)	220/380/415	220/380/415	3P/380/50HZ
Motor Power(kw)	0.75	1.5	2.2
Dimension(L.W.H) (mm)	3540x1470x1420	4040x2410x1420	4340x3350x1420
N.W.(kg)	1500	3050	4350

Industry Trends

The commercial laundry industry is constantly evolving, with new technologies and innovations being developed to improve the efficiency and quality of laundry services. One trend that has gained popularity in recent years is the use of energy-efficient laundry equipment, such as the 5 rolls clean sheet automatic laundry flatwork ironer with steam heating function. This trend is driven by the need to reduce energy costs and minimize the environmental impact of commercial laundry operations. Another trend is the use of automation and robotics to streamline the laundry process and reduce labor costs. This includes the use of robotic arms to sort and transport laundry, as well as the use of computerized systems to monitor and control the laundry equipment.

Product Description

Use: Y series roller automatic flat-work ironing machine is a new product developed by our company with Sino-foreign technology. It is suitable for star-level hotels, restaurants, hospitals, railways, larger washing centers, washing-dyeing factories, and industrial-mining enterprises. It is used to make ironing and finishing for flat fabrics like bedsheets, bedcovers, and tablecloths after washing and extracting.

Short introduction: Efficiently irons fabrics with duplex and no trace, ensuring high-quality ironing effect. This equipment is made of high-precision 304 stainless steel drum for long service life. Frequency conversion drives allow users to adjust ironing speed depending on different fabrics, improving ironing efficiency. Programmable computer controlled, multi-language control panel, large screen LCD, and man-machine interface make it easy to operate.

Using frequency-conversion motor, reducer, and chains transmission for smooth operation; equipped with buffer and auto adjustment conveying system, no guide strips needed for precise conveying. Safe electrical-pneumatic design can stop the machine in emergency situations to ensure operator safety.

After Sales Service

The whole machine has been guaranteed for 1 year
Providing lifelong technical support
Guarantee of spare parts supply
Engineers available to service machinery overseas

Installation and Test

Free technical training at factory
Free technical guide through network
On-site service under contract

Warranty

Main spare parts (except consumable accessories) under ONE YEAR warranty with defects from manufacturer by free shipping.
