16kg Perc Dry Cleaning Machine With 45 Centrifugal Filter Volume

Product Details

Product Name:

Hydrocarbon Dry Cleaning Machine

Rated Capacity(kg):

8,10,12

Solvent:

Hydrocarbon

Diameter:

800mm

Volume:

170

Depth:

340

Centrifugal Filter Volume:

Brand:

YASEN

Highlight:

800mm diameter hydrocarbon dry cleaning machine

10kg hydrocarbon dry cleaning machine

800mm diameter hydrocarbon cleaning machine

Payment & Shipping Terms

Minimum Order Quantity

1pc

Price

$8,000.00 - $30,000.00/sets

Packaging Details

Wooden packing

Supply Ability

30 Set/Sets per Month dry cleaning machines price list

Steam Heating Hospital Hydrocarbon Dry Cleaning Equipment Stainless steel 3 tanks

Get Best Price

Eco Friendly Dry Cleaning Solutions Hospital Hydrocarbon Dry Cleaning Equipment

Get Best Price

Two Tanks HydroCarbon Multi Solvent Dry Cleaning Machine

Get Best Price

2 Tanks Multi Solvent, Stainless Steel Steam Heating Clothes Hydrocarbon Dry Cleaning Machine

Get Best Price

Contact Now

Product Description

16kg Perc Dry Cleaning Machine With 45 Centrifugal Filter Volume

The Hydrocarbon Dry Cleaning Machine is a specialized piece of equipment that utilizes hydrocarbon solvents for the efficient and environmentally friendly cleaning of garments, linens, and other textiles. It is designed to provide a safe and cost-effective solution for dry cleaning operations in various industries, including hospitals, hotels, and commercial laundries.

Features and Specifications

Solvent Type: The machine uses hydrocarbon solvents, which are known for their excellent cleaning power and low environmental impact.
Cleaning Capacity: Depending on the model, the Hydrocarbon Dry Cleaning Machine can handle various cleaning capacities, ranging from 8kg to larger capacities suitable for commercial use.
Environmental Protection: The machine is designed with environmental protection in mind. It has a solvent recycling rate of up to 95%, significantly reducing solvent consumption and waste.
Multiple Tanks: The solvent tank system typically consists of three tanks, allowing for efficient solvent distribution and recycling.
Cooling Method: The solvent recycling process utilizes water cooling, ensuring stable and efficient operation of the machine.

Working Principle

Loading: Garments, linens, or other textiles are loaded into the machine's drum or basket.
Solvent Application: The hydrocarbon solvent is distributed throughout the drum, thoroughly soaking the items to be cleaned.
Agitation: The drum rotates or agitates to loosen dirt, stains, and other impurities from the textiles.
Extraction: The solvent, along with the loosened dirt and stains, is extracted from the textiles through the use of filters and separators.
Solvent Recycling: The extracted solvent is then sent to the recycling system. Here, it is filtered, cooled, and reconditioned for reuse.
Drying: After the cleaning process, the textiles are dried by circulating warm air through the drum, removing any residual solvent.
Unloading: Once dried, the cleaned textiles are unloaded from the machine and ready for use.

Product Parameters

Name: Perchloroethylene dry cleaning machine

LS Series

Attributes	LS-612C	LS-608C	LS-610C
Washing Capacity (kg)	12	8	10
Capacity of drum (L)	198	140	170
Washing Speed (r/min)	38	38	38
Extracting Speed (r/min)	400	400	400
Hydraulic Pump Power (kw)	0.55	0.55	0.55
Drive Motor Power (kw)	2.2	1.5	2.2
Filter Motor (kw)	0.55	0.55	0.55
Power Supply (V)	220/380/415	220/380/415	220/380/415
Frequency (Hz)	50	50	50
Dimension (L.W.H) (mm)	1820×1330×2200	1680×1250×1970	1680×1250×1970
N.W. (kg)	1280	980	1150

Category	LS 816	LS 820	LS 825
Washing Capacity (kg)	16	20	25
Capacity of volume (L)	280	340	425
Capacity of diameter (mm)	Φ900	Φ900	Φ900
Power Supply (V/P/Hz)	380/3/50	380/3/50	380/3/50
Drive Motor Power (kw)	2.2	3	4
Hydraulic Pump Power (kw)	0.75	0.55	0.55
Power electric heating (kw)	23.7	24.5	24.5
Power steam heating (kw)	8.7	9.5	10.5
Steam pressure (MPa)	0.4-0.6	0.4-0.6	0.4-0.6
N.W. (kg)	1850	2020	2280
Dimension (L.W.H) (mm)	2015×1570×2250	2015×1662×2250	2015×1795×2250

Key Features

With washing, extracting, and drying function in one machine.
Fully automatic and fully enclosed, easy to operate, repair and testing more convenient.
Stainless steel drum, good appearance.
With recycle working system, recycling rate can reach to 99.8%, save solvent (perchloroethylene), no pollution to the air, no harm to the users.
Heating type: electricity or steam.

After Sales Service

The whole machine has been guaranteed for 1 year.

Providing lifelong technical support.

Guarantee of spare parts supply.

Engineers available to service machinery overseas.
