Hotel Laundry And Hospital Stainless Steel Automatic Flatwork Ironer Machine

Hotel Laundry flatwork ironer machine

Hospital flatwork ironer machine

Stainless Steel flatwork ironer machine

Place of Origin:

Shanghai, China

Brand Name:

YASEN

Certification:

CE/OHSAS18001/ISO14001

Request A Quote

Hotel Laundry And Hospital Stainless Steel Automatic Flatwork Ironer Machine

Product Details

Product Name:

Stainless Steel Flatwork Ironer Machine

Material:

Stainless Steel

Used For:

Hotel Laundry And Hospital

Power:

1.5kw

Capacity:

1.6m,2.5m,2.8m,3m,3.3m

Power Supply:

380/3/50 (V/p/Hz)

Warranty:

1 Year, Warranty

Brand:

YASEN

Highlight:

Hotel Laundry flatwork ironer machine

Hospital flatwork ironer machine

Stainless Steel flatwork ironer machine

Payment & Shipping Terms

Minimum Order Quantity

1pc

Price

$4,200.00 - $20,000.00/sets

Packaging Details

WOODEN PACKAGE

Supply Ability

100 Set/Sets per Month

Fully Automatic Flatwork Ironer Machine for Commercial Laundry

Get Best Price

800mm Roll Diameter Single Roller Iron Steam for Prison Laundry Shop Flatwork Ironing

Get Best Price

3050kg Stainless Steel Ironing Bedsheet And Clothes Folding Machine With Iron Function

Get Best Price

5 Rolls Clean Sheet Automatic Laundry Flatwork Ironer With Steam Heating Function

Get Best Price

Contact Now

Product Description

Hotel Laundry And Hospital Stainless Steel Automatic Flatwork Ironer Machine

Product Overview

The Hotel Laundry and Hospital Stainless Steel Automatic Flatwork Ironer Machine is a highly sophisticated and essential piece of equipment engineered with precision and built using high-quality stainless steel to meet the rigorous demands of hotel and hospital laundry operations.

In hotels, it helps maintain high standards of cleanliness and presentation expected by guests, quickly and effectively handling large volumes of sheets, pillowcases, and other linens. In hospitals, it ensures the sterility and freshness of medical linens and uniforms.

The machine features a user-friendly interface for easy operation and adjustment, minimizing the need for extensive operator training. It offers enhanced productivity and efficiency, reducing labor costs and turnaround times.

Technical Specifications - Series Y-3000/3300

Attributes	Y-3000IZ/D	Y-3000IIZ/D	Y-3000IIIZ	Y-3000IVZ	Y-3000VZ	Y-3000VIZ
Max Feeding Width (mm)	3000/3300	3000/3300	3000/3300	3000/3300	3000/3300	3000/3300
Roll Diameter (mm)	800	800	800	800	800	800
Rolls Quantity	1	2	3	4	5	6
Ironing Speed (m/min)	0-9	0-15	0-22	0-30	0-35	0-40
Rating v/p/Hz	380/3/50	380/3/50	380/3/50	380/3/50	380/3/50	380/3/50
Motor Power (kw)	1.5	1.5	2.2	1.5*2	2.2*2	2.2*2
Steam Pressure (Mpa)	0.3-0.6	0.3-0.6	0.3-0.6	0.3-0.6	0.3-0.6	0.3-0.6
Steam Inlet (Inch)	G1 1/2″	G1 1/2″	G1 1/2″	G1 1/2″	G1 1/2″	G1 1/2″
Drain Outlet (Inch)	G1 1/2″	G1 1/2″	G1 1/2″	G1 1/2″	G1 1/2″	G1 1/2″
Electric Heating Power (kw)	36	70	/	/	/	/
Steam Consumption (kg/h)	2200 2400	3000 3400	3800 4400	4600 5400	5400 6400	6200 7200
Dimension (L.W.H) (mm)	4080×1568×1302 4380×1568×1302	4080×2508×1302 4380×2508×1302	4080×3448×1302 4380×3448×1302	4080×4388×1302 4380×4388×1302	4080×5328×1302 4380×5328×1302	4080×6268×1302 4380×6268×1302

Technical Specifications - Series Y-8033 & Y-6833

Attributes	Y-8033IVS	Y-8033VIS	Y-6833IVS	Y-6833VIS
Max Feeding Width (mm)	3300	3300	3300	3300
Roll Diameter (mm)	800	800	680	680
Rolls Quantity	4	6	4	6
Ironing Speed (m/min)	10-40	10-60	10-40	10-50
Rating v/p/Hz	380/3/50	380/3/50	380/3/50	380/3/50
Motor Power (kw)	5.15	7.35	4.75	5.25
Steam Pressure (Mpa)	0.3-1.0	0.3-1.0	0.3-1.0	0.3-1.0
Steam Inlet (Inch)	DN50	DN50	DN50	DN50
Drain Outlet (Inch)	DN50	DN50	DN50	DN50
Total Weight (kg)	11000	16000	9500	13000
Dimension (L.W.H) (mm)	4640×4106×1946	4640×5742×1946	4640×3480×1658	4640×4860×1658

Technical Specifications - Series GY

Attributes	GY-13033IZ	GY-13033IIZ	GY-13033IIIZ	GY-8033IIZ	GY-8033IIIZ
Max Feeding Width (mm)	3300	3300	3300	3300	3300
Roll Diameter (mm)	1300	1300	1300	800	800
Rolls Quantity	1	2	3	2	3
Ironing Speed (m/min)	3~25	3~40	3~50	3~25	3~40
Steam Pressure (Mpa)	0.6-0.8	0.6-0.8	0.6-0.8	0.6-0.8	0.6-0.8
Steam Inlet (Inch)	G2″	G2″	G2″	G2″	G2″
Drain Outlet (Inch)	G2″	G2″	G2″	G2″	G2″
Steam Consumption (kg/h)	230	460	580	230	460
Exhaust Outlet (mm)	Φ200	Φ200	Φ200	Φ200	Φ200
Air Output (mm)	2200	3500	5500	2400	3600
Drive Motor Power (kw)	9.2	9.2×2	9.2×3	3×2	3×3
Conveyor Motor Power (kw)	0.75	1.5	1.5	0.75	0.75
Rating v/p/Hz	380/3/50	380/3/50	380/3/50	380/3/50	380/3/50
Electric Heating Power (kw)	11.5	22.9	33.6	9.8	14.3
Blower Power (kw)	1.5	1.5×2	1.5×3	1.5×2	1.5×3
Total Weight (kg)	5500	11000	16000	7800	9800
Dimension (L.W.H) (mm)	4865×2880×2200	4865×4550×2200	4865×6210×2200	4630×3510×1900	4630×4660×1900

Applications & Features

Applications

Y series roller automatic flat-work ironing machine is suitable for star-level hotels, restaurants, hospitals, railways, larger washing centers, washing-dyeing factories, and industrial-mining enterprises. It is used for ironing and finishing flat fabrics like bedsheets, bedcovers, and table cloths after washing and extracting.

Key Features

Efficiently irons fabrics with duplex and no trace, ensuring high-quality ironing effect
Made of high-precision 304 stainless steel drum for long service life
Frequency conversion drives allow users to adjust ironing speed based on different fabrics
Programmable computer controlled with multi-language control panel and large screen LCD
User-friendly man-machine interface for easy operation
Uses frequency-conversion motor, reducer, and chains transmission for smooth operation
Equipped with buffer and auto adjustment conveying system, no guide strips needed
Safe electrical-pneumatic design with emergency stop function for operator safety

After-Sales Service & Support

Whole machine guaranteed for 1 year
Lifelong technical support
Guaranteed spare parts supply
Engineers available for overseas service
Free technical training at factory
Free technical guidance through network
On-site service available under contract
Main spare parts (except consumable accessories) under ONE YEAR warranty with free shipping for defects

Additional Technical Specifications

Attributes	Y-1600I	Y-2500I	Y-2800I	Y-3000II	Y-3300III
Max Feeding Width (mm)	1600	2500	2800	3000	3300
Rolls Quantity	1	1	1	2	3
Roll Diameter (mm)	800	800	800	800	800
Ironing Speed (m/min)	0-9	0-9	0-9	0-18	0-25
Electric Heating Power (kw)	18	27	36	64	96
Steam Pressure (Mpa)	0.3-0.6	0.3-0.6	0.3-0.6	0.3-0.6	0.3-0.6
Steam Consumption (kg/h)	80	120	250	250	320
Steam Inlet (Inch)	G1.5"	G1.5"	G1.5"	G1.5"	G1.5"
Drain Outlet (Inch)	G1.5"	G1.5"	G1.5"	G1.5"	G1.5"
Rated Voltage (V)	3P/220V/380V	3P/220V/380V	3P/220V/380V	3P/220V/380V	3P/220V/380V
Motor Power (kw)	0.75	0.75	1.5	1.5	2.2
Dimension (L.W.H) (mm)	1600×1300×1270	3500×1300×1270	3840×1300×1270	4040×2410×1420	4340×3350×1420
Net Weight (kg)	750	1100	1300	3050	4350
